TM-Roof-Roll RB for roof ridges and burrs.
And all accessories for roof waterproofing.

TM Roof Roll RB for roof ridges and burrs plus roof waterproofing accessories. The optimal roof ventilation and roof waterproofing from the roll with the simultaneous protection against

The TM Roof Roll RB for roof ridges and burrs in brief is a simple and fast solution.  For the safe ventilation of roof and ridge.  Especially for pitched roofs

The technical regulations of the German craftsmen’s association require secure and permanent ventilation under the roof covering, so that damage from dampness can be prevented. By combining several different materials we have succeeded in creating a compact system which fulfils the requirements for extract ventilation and protection from rain and snow. The special structure of the fabric guarantees the ventilation through the ridge and the hips. Despite its open surface TM Roof Roll RB remains watertight and thus offers maximum protection against moisture.
TM Roof Roll RB is very flexible and almost lays itself on the top row of pan tiles.

As a result of the soft aluminum material laid in pleats
TM Roof Roll is also highly suitable for heavily-profiled roof tiles.
The easily formable and flexible corrugated aluminum sheeting
offers a secure seating when being aligned

The specially-developed fabric structure allows air to pass through its open
surface but is water-repellent, and there is practically no capillary action.
Through the different bands of color the middle of the roll is clearly
recognizable and it is thus easy to line it up along the ridge battens

Double protection through the adhesive and sewn seam.

The butyl rubber adhesive strip possesses outstanding adhesive
properties even at extreme temperatures. It also has high resistance to
UV-radiation and is water-tight. The adhesive properties are only
activated after the covering- foil is peeled off..

•  Universally applicable for almost all concrete roofing tiles and beaver tails with a
    very good adjustment also on strongly formed roof pans

•   high security against rains and snow

•  the ventilation cross section of the special fabric corresponds to the

    specialized rules of the German roofer handicraft and the DIN 4108 part of 3

Laying instructions

   •    after the Ridge Batten was fastened to holding, the  roofing tiles
   •   must be cleaned of loose dust and dirt

   •   The TM-Roof-Roll RB rolling roof and align
   •   subsequently, the fabric on the Ridge-Batten nail down by stapler.
   •   The masking of the butyl rubber adhesive strips removes as soon
        as the roll is adjusted in the wave field, the tape is firmly pressed
   •   can be laid easily and in any weather
   •   tested quality


Advantages the TM Roof Roll RB

• UV stabilized and weather resistant
• high temperature resistance of the adhesive strip
• weather-independent and easy installation
• examined + tested quality

With professional installation we give due to these excellent material qualities Ten Years Warranty


TM Roof-Roll RB during application
