TM - HD-PE Sealing Foils
Technical Data
|
|
|
|
|
Thickness
|
Width
|
Folding / Flat
|
Length
|
|
0,50 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
0,75 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
1,00 mm
|
0,5 – 6,0 m
|
flat
|
200 m
|
|
1,50 mm
|
0,5 – 6,0 m
|
flat
|
135 m
|
|
2,00 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
2,50 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
|
|
|
Confection / CUTS
Based on
your specific request, the Confection of TM Sealing Foils is possible locally and/or where these are used.
We are able to produce these foils with a Net weight up to 2,000 kg.
The
TM Seal Foils
are produced with modern Technology and specialty raw materials manufactures and continuously optimized.
Due to excellent mechanical properties, high flexibility and high breakthrough firmness and very good welding characteristics meet
TM Seal Foils the special requirements in the environmental and hydraulic engineering.
|
|
|
|
|
TM - LD-PE Sealing Foils
Technical Data
|
|
|
|
|
Thickness
|
Width
|
Folding / Flat
|
Length
|
|
0,50 mm
|
4,0 / 6,0 / 8,0 m
|
folded
|
25 m
|
|
0,50 mm
|
10,0 m
|
folded
|
100 m
|
|
0,80 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
0,80 mm
|
6,0 m
|
folded
|
200 m
|
|
1,00 mm
|
0,5 – 6,0 m
|
flat
|
200 m
|
|
1,00 mm
|
6,0 m
|
folded
|
25 m
|
|
1,00 mm
|
6,0 m
|
folded
|
200 m
|
|
1,00 mm
|
8,0 m
|
folded
|
100 m
|
|
1,50 mm
|
0,5 – 6,0 m
|
flat
|
135 m
|
|
2,00 mm
|
0,5 – 6,0 m
|
flat
|
100 m
|
|
|
|
|
TM Seal Sheets Characteristics
• UV stable
• Chemically highly
• Connection without welds
|
|
