For DIY TWIN WALL PANELS made of Polycarbonate


TERRA-LUX

Transparency + Protection

Widths                               0, 20 m
Lengths - Standards:    200 cm - 250 cm - 300 cm
Special lengths:             600 cm at maximum. On request, accurate cuts.

With TWIN-WALL-PANELS made of Polycarbonate can be varied requirements on the form and appearance and reliability can be realized.
The material is virtually indestructible thanks to the high bending ability, even for circular or semicircular shapes / design ideally suited.
The material is by special allowance (co-extrusion) weather-resistant.

A 10-years warranty (in accordance with terms of the warranty) against yellowing and, stood for aging, even against hail impact for long-term protection and security.
Polycarbonate is unbreakable.
The DIY TWIN-WALL-PANELS with the favorable widths of 20 cm make the qualified or ambitious do-it-yourselves to work much easier and faster.
This supports a tight, but sufficient for every purpose

The SYSTEM ACCESSORIES
Accessories must be problem-solutions: useful, practical + fast in processing - permanently + attractive as a result!
For a variety of applications on the roof + walls, we offer very useful
Aluminum Profiles, as well as supplementing accessories...
All accessories are specially adapted to the strength of the 16 mm Double Wall Panels vote - both for the PVC-Hard, as well as the Polycarbonate Panels.
The Aluminum Profiles are high-proven + reliable. Otherwise usual or necessary additional seals are not needed or used in our system!

Please call our special SYSTEM information by e-mail – see page Contact!
The double wall panels are generally without Aluminum Profiles connected - the system- profiles of the sensible or necessary optimize the overall design, such as edging, roof or wall sockets, 90 ° corner joints etc...
Due to the excellent heat and cold and sound insulation properties, according to a 20 mm insulating!
System Profiles are used for meaningful and necessary optimization of the overall design, such as edging, roof or wall sockets, 90 ° corner joints etc...
